Busbar type mini current transformer

Features

Meet the standard IEC60044-1 and ANSI C12.20
High accuracy class ,wide linearity
Superitor stability ,separate the external magneitc field interference
Measure the current directly
It is with the diode to save people's life
Meet the ROHS requirement



Specifications



No. Name                               Materials  /UL
1 Core  N42UU20.6
2 Winding                            2UEW/130  MW75-C   Φ0.16E255929
3 Outer Case                       PA66 70G33L    E41938
4 Lead  Wire                      UL1015 22AWG 600V 105°c (L=600mm)
5 Diode                        IN4738A 1W




Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
OEM
Model Number:
CT-002
Usage:
Current
Phase:
Single
Coil Structure:
Toroidal, Micro Precision current transformer
Coil Number:
Autotransformer
standard:
IEC60044-1 and ANSI C12.20
Color:
white
inner hole:
7mm
Outer Case:
PA66 70G33L E41938
Lead Wire:
UL1015 22AWG 600V 105°c (L=600mm)
Core:
N42UU20.6
Electric meter current transformer:
Epoxy Encapsulated transformer
is_customized:
Yes


 Features

Meet the standard IEC60044-1 and ANSI C12.20
High accuracy class ,wide linearity
Superitor stability ,separate the external magneitc field interference
Measure the current directly
It is with the diode to save people's life
Meet the ROHS requirement



Specifications



No. Name                               Materials  /UL
1 Core  N42UU20.6
2 Winding                            2UEW/130  MW75-C   Φ0.16E255929
3 Outer Case                       PA66 70G33L    E41938
4 Lead  Wire                      UL1015 22AWG 600V 105°c (L=600mm)
5 Diode                        IN4738A 1W
